Drive DeVilbiss 10 Liter Oxygen Concentrator

The DeVilbiss Oxygen Concentrator 10 Liter – Overview

Designed to provide optimal oxygen delivery, the DeVilbiss 10 Liter Oxygen Concentrator only weighs 42 pounds, making it significantly lighter than most high volume concentrators. This 10 liter unit also utilizes a compact shell that is similar to the 525, which makes it one of the smallest high-volume concentrators on the market. For patients who require varying flow, the DeVilbiss Oxygen Concentrator 10 Liter provides optimal oxygen delivery. This unit is capable of delivering 87% to 96% oxygen purity from 2 LPM to 10 LPM.

It features an easy-to-use display panel, with a flow meter and lockable flow control knob, and four LED indicators making it easy for patients to determine the operating status of their machine. It requires minimal maintenance and is backed by a three-year manufacturer warranty. The device has been tested for altitudes up to 5,000 feet above sea level.

To ensure the most from your oxygen therapy, a 7’ nasal cannula and oxygen tubing no longer than 50 feet is recommended. If your prescription requires airflow greater than 5 liters per minute (LPM), be sure that your nasal cannula is rated for high flow oxygen to ensure proper breath detection and oxygen delivery (i.e. Salter Labs 1600HF, 16SOFT-HF-7).

Drive DeVilbiss 10 Liter Oxygen Concentrator – Smart Design

The DeVilbiss Oxygen Sensing Device (OSD) is a proprietary oxygen sensing technology used by the Drive DeVilbiss Oxygen Concentrator. The device provides correct oxygen delivery by continuously measuring the amount of oxygen generated.

The DeVilbiss Oxygen Concentrator 10 LPM device also features a built-in humidifier nook for users who prefer to use a humidifier bottle with their oxygen therapy. To connect the humidifier, simply attach the tubing from the lid to the cannula fitting on the device. Once attached, connect the oxygen tubing or nasal cannula to the fitting on the humidifier lid. Be sure the humidifier is not filled past the max fill line and is securely placed on the shelf.

Another design feature of this oxygen concentrator is portability. The convenient top and side handles make carrying the device a breeze, and sturdy wheels allow you to move it from room to room without a second thought. The DeVilbiss 10 LPM Concentrator has been rigorously tested to withstand even the highest temperatures. Users have the ability to refill the oxygen cylinders at home with this device through the auxiliary port that is compatible with most transfill systems. To help users with this task, the machine has bright LEDs, accessible patient controls, and a humidifier nook to protect the humidifier from damage. The optional transfill caddy is required to fill oxygen tanks that have to be bought separately.

DeVilbiss Oxygen Concentrator 10 Liter – Highlights

• Continuous Flow: 2-10 LPM.
• Weight: 42lbs; this unit is substantially smaller and lighter than most competitive concentrators.
• Operating volume: less than 69 dBA .
• Accommodates up to 50 feet of oxygen tubing plus a nasal cannula with up to 7-foot tubing.
• Convenient top and side handles to move the unit around.

NOTE: If your oxygen flow is above 6LPM, a single lumen high flow cannula, rated for 6-15 liters per minute is recommended to ensure proper breath detection and oxygen delivery (i.e. Salter Labs 1600HF, 16SOFT-HF-7)

DeVilbiss 10 Liter Oxygen Concentrator – In the Box

• DeVilbiss 10 Liter Home Concentrator
• AC Power Cord
• Pre Installed Filter Kit
• 1 Christmas Tree Adapter
• User Manual & 3 Year Manufacturer Warranty
• 5 Nasal Cannulas
